Size 54
Hover a size to preview it on the drawing. Tap Compare under a column to line sizes up side by side.
47 | 50 | 52 | 54 | 56 | 58 | 60 | 62 | |
|---|---|---|---|---|---|---|---|---|
| Price (CAD) | $5,754 | $5,754 | $5,754 | $5,754 | $5,754 | $5,754 | $5,754 | $5,754 |
| Frame kit (g) | 1620 | 1620 | 1620 | 1620 | 1620 | 1620 | 1620 | 1620 |
| Stack | 527 mm | 546 mm | 561 mm | 575 mm | 591 mm | 611 mm | 632 mm | 656 mm |
| Reach | 364 mm | 368 mm | 371 mm | 374 mm | 377 mm | 380 mm | 383 mm | 386 mm |
| Stack / Reach | 1.45 | 1.48 | 1.51 | 1.54 | 1.57 | 1.61 | 1.65 | 1.70 |
| Head tube angle | 71° | 71.1° | 71.3° | 71.3° | 71.9° | 72° | 72.1° | 72.1° |
| Seat tube angle (effective) | 74.6° | 74.6° | 74.2° | 73.7° | 73.3° | 73° | 72.8° | 72.5° |
| Seat tube angle (actual) | — | — | — | — | — | — | — | — |
| Top tube (effective) | 509 mm | 519 mm | 530 mm | 542 mm | 554 mm | 567 mm | 579 mm | 593 mm |
| Head tube length | 110 mm | 130 mm | 145 mm | 160 mm | 175 mm | 195 mm | 220 mm | 245 mm |
| Seat tube length | 420 mm | 450 mm | 475 mm | 500 mm | 525 mm | 548 mm | 567 mm | 586 mm |
| Bottom bracket drop | 80 mm | 80 mm | 80 mm | 80 mm | 78 mm | 78 mm | 75 mm | 75 mm |
| Bottom bracket height | — | — | — | — | — | — | — | — |
| Chainstay | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 425 mm | 425 mm | 425 mm |
| Front center | 579 mm | 589 mm | 596 mm | 603 mm | 600 mm | 609 mm | 618 mm | 628 mm |
| Wheelbase | 986 mm | 996 mm | 1003 mm | 1010 mm | 1008 mm | 1022 mm | 1032 mm | 1042 mm |
| Fork rake (offset) | 53 mm | 53 mm | 53 mm | 53 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Fork axle to crown | 380 mm | 380 mm | 380 mm | 380 mm | 380 mm | 380 mm | 380 mm | 380 mm |
| Trail | 61 mm | 60 mm | 59 mm | 59 mm | 61 mm | 60 mm | 59 mm | 59 mm |
| Standover | 686 mm | 716 mm | 735 mm | 754 mm | 776 mm | 796 mm | 817 mm | 835 mm |
| Pad / effective stack | — | — | — | — | — | — | — | — |
| Pad / effective reach | — | — | — | — | — | — | — | — |
